7-4 Control setting when unvented cylinder is connected.
・
・
The followings are examples to paste 9 sensors on the unvented cylinder.
Example 1
Example 2
Hot water outlet
Hot water outlet
Heat
pump
water heater
Heat
pump
water heater
For 3000Liter (6 x 500Liter) cylinder
For 4000Liter (8 x 500Liter) cylinder
Clean water and return
Clean water and return
