Operator user‟s manual
48/78
4.2.1.1 Installing the system as an Order Terminal
In order to use the easyphoto as an Order Terminal, it‟s necessary, after activating the license,
changing the working mode and setting the network parameters. This can be done in 2 different
ways: Basic and Advanced Mode.
For a basic lan connection (using a crossover network cable or ethernet hub), it‟s recommended
to use the Basic Mode, because of the easier setup. When the system is attached to a
corporate lan, it‟s better to use the Advanced Mode.
The Click5000 of the Flexilab system needs to run software version 2.4.0 or above in order to
support an attached easyphoto working as an Order Terminal. The shared resources of
Click5000 must allow file writing operations to the client machines:
D:\APPLICATIONS\ORDER_TERMINAL shared as „OTFOLDER‟
D:\KERNEL\SERVICE_MODULES\DPSLAB_LISTENER\INCOMING_ORDERS shared
as „ERequest‟
Steps to follow for installing the easyphoto as Order Terminal (Basic mode)
a) Please connect both Click5000 and easyphoto systems with a crossover network cable
or Ethernet hub, and switch on both systems.
b) If the easyphoto system was never activated as an Order Terminal before, please be
sure that you have your Activation Key, and proceed to next step. See chapter 6 for
more information about licensing. If you are not sure if the system was already activated
in the past, please proceed to next step anyway.
c) Go to Settings Main and select the „Order Terminal Mode‟. If any Activation Key is
asked, please enter it now. For more information please see chapter 6 of this manual.
d) Now it‟s necessary to configure Network settings. Please go to Settings Devices
Network.
