Accessories 7 - 23
Figure 7-24
Enter PIN
Chip and PIN Transactions
Launch a transaction application on the MC75A. In the application, select Chip and PIN transaction.
Customer inserts the Chip and Pin card into the slot, orienting the card with the contacts facing down and toward
the DCR keypad.
Figure 7-25
Insert Card
Customer turns the MC75A over, and enters their PIN following the instructions on the display.
Customer removes the card when transaction is complete.
Keypad
The back of the module contains a display and a numeric keypad for entering data.
NOTE Chip and PIN transactions will function without an encryption key injected but will not function if a tamper event
occurs.
