Getting Started 1 - 9
4. Replace the memory card cover and tighten the screws.
Adjusting the Handstrap
The MC75A handstrap is attached to the bottom of the battery cover. Adjust the handstrap to increase comfort
when holding the MC75A for extended periods of time. To adjust the handstrap:
1. Feed the handstrap through the handstrap slot.
2. Secure the handstrap by pressing the two sides together as shown in Figure 1-10.
Figure 1-10
Handstrap Adjustment
Replacing the Main Battery
3. If the MC75A is in suspend mode, press the red Power button to wake the device.
4. Press the red Power button to suspend the MC75A.
5. Wait for red Decode LED to turn on and then turn off.
6. Open the battery cover latches on either side of the battery cover.
To Next Page
