ＮＩＳＳＥＩ ＣＯＲＰＯＲＡＴＩＯＮ E6581815
J-1
10
10. Peripheral devices
Warning
Mandatory
action
When using switchgear for the inverter, it must be installed in a cabinet.
Failure to do so can lead to risk of electric shock and can result in death or serious injury.
Be Grounded
Connect grounding cables securely.
Failure to do so can lead to risk of electric shock or fire in case of a failure or short-circuit or electric
leak.
10.1 Selection of wiring materials and devices
Wire size (See Note 4)
Power circuit
(mm
2
) (Note 1.)
DC reactor
(optional) (mm
2
)
Grounding cable
(mm
2
)
Voltage class
Capacity of
applicable
motor (kW)
Inverter model
IEC
compliant
For Japan
(JEAC800
1-2005)
IEC
compliant
For Japan
(JEAC800
1-2005)
IEC
compliant
For Japan
(JEAC800
1-2005)
0.1 VFNC3M-2001P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.2 VFNC3M-2002P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.4 VFNC3M-2004P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
0.75 VFNC3M-2007P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
1.5 VFNC3M-2015P 1.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
Three-phase
240V class
2.2 VFNC3M-2022P 2.5(1.5) 2.0(2.0) 1.5 2.0 2.5 2.0
Note 1: Sizes of the wires connected to the input terminals R/L1, S/L2 and T/L3 and the output terminals U/T1,
V/T2 and W/T3 when the length of each wire does not exceed 30m.
The numeric values in parentheses refer to the sizes of wires to be used when a DC reactor is connected.
Note 2: For the control circuit, use shielded wires 0.75 mm
2
or more in diameter.
Note 3: For grounding, use a cable with a size equal to or larger than the above.
Note 4: The wire sizes specified in the above table apply to HIV wires (cupper wires shielded with an insulator
with a maximum allowable temperature of 75°C) used at an ambient temperature of 50°C or less.
Note 5: If there is a need to bring the inverter into UL compliance, use wires specified in chapter 9.
