ＮＩＳＳＥＩ ＣＯＲＰＯＲＡＴＩＯＮ E6581815
E-12
5
5.7 Maximum frequency
: Maximum frequency
Function
1) Programs the range of frequencies output by the inverter (maximum output values).
2) This frequency is used as the reference for acceleration/deceleration time.
Output frequency
(Hz)
When =125Hz
When =83.4Hz
125Hz
83.4Hz
0 100% Frequency setting signal (%)
・This function determines the value
in line with the ratings of the motor
and load.
・Maximum frequency cannot be
adjusted during operation.To
ad
ust
first sto
the inverter.
+ If is increased, adjust the upper limit frequency as necessary.
[Parameter setting]
Title Function Adjustment range Default setting
Maximum frequency 30.0-400.0 (Hz)
0.1k to 0.4kW model : 83.4
0.75k to 2.2kW model : 125
Note) The permission maximum rotary speed of our IPM gear motor is to 2500 rpm.
Set the frequency 2500 rpm or less.
(Inverter maximum frequency: 0.1k to 0.4kW model: 83.4Hz or less, 0.75 to 2.2kW model: 125Hz or less)
