3.3 Meter setting and adjustment
 : Meter selection
 : Meter adjustment gain
 Function
Output of 0 - 1mAdc, 0 (4) - 20mAdc, 0 - 10vdc can be selected for the output signal from the FM
terminal, depending no the  setting. Adjust the scale at .
Use an ammeter with a full-scale 0 - 1mAdc meter.
The  (analog output bias) needs to be adjusted if output is 4 - 20mAdc.
[Parameter setting]
Title Function Adjustment range
Supposition output at
fsl=17
Default setting

Meter
selection
0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5: Input power
6: Output power
7 to 10: -
11: PBR (Braking resistor) cumulative
load factor
12: Actual output frequency
13: VI input value
14: -
15: Fixed output 1
(output current 100% equivalent)
16: Fixed output 2
(output current 50% equivalent)
17: Fixed output 3
(other than the output current)
18: RS485 communication data
19: For adjustments ( set value is
displayed)
20 to 22: -
Maximum frequency ()
-
Maximum frequency (fh)
1.5x rated voltage
1.5x rated voltage
1.85x rated power
1.85x rated power
-
Rated load factor
Maximum frequency (fh)
Maximum input value
-
-
-
-
Maximum value (100.0%)
-
-
0

Meter
adjustment
gain
- - -
