ＮＩＳＳＥＩ ＣＯＲＰＯＲＡＴＩＯＮ E6581815
K-17
11
11.4 Input Terminal Function
It can be assigned the function No. in the following table to parameter f104, f108, f110~f115, f151~f156.
Table of input terminal functions 1
Function
No.
Code Function Action Reference
0,1 - No function Disabled -
2 F Forward run command ON: Forward run, OFF: Slowdown stop 7.2.1
3 FN Inversion of forward run command Inversion of F
4 R Reverse run command ON: Reverse run, OFF: Slowdown stop
5 RN Inversion of reverse run command Inversion of R
6 ST Standby ON: Ready for operation
OFF: Coast stop (gate OFF)
6.3.2
7 STN Inversion of standby Inversion of ST
8 RES Reset command ON: Acceptance of reset command
ON ¤ OFF: Trip reset
13.2
9 RESN Inversion of reset command Inversion of RES
10 SS1 Preset-speed command 1 3.5
11 SS1N Inversion of preset-speed command 1 7.2.1
12 SS2 Preset-speed command 2
13 SS2N Inversion of preset-speed command 2
14 SS3 Preset-speed command 3
15 SS3N Inversion of preset-speed command 3
16 SS4 Preset-speed command 4
17 SS4N Inversion of preset-speed command 4
Selection of 15-speed SS1 to SS4 (SS1N to SS4N) (4 bits)
18 JOG Jog run mode ON: Jogging mode (fixed at 5Hz)
OFF: Jog run canceled
7.2.1
19 JOGN Inversion of jog run mode Inversion of JOG
20 EXT Emergency stop by external signal ON: trip stop
OFF: After stopped by f603, e trip
6.18.4
21 EXTN Inversion of emergency stop by external signal Inversion of EXT
24 AD2 2nd acceleration/deceleration ON: Acceleration/deceleration 2
OFF: Acceleration/deceleration 1
6.17.1
25 AD2N Inversion of 2nd acceleration/deceleration Inversion of AD2
32 OC stall Torque limit switching ON: Torque limit 2 limiting operation
OFF: Torque limit 1 limiting operation
6.15.1
33 OC stall
N
Inversion of torque limit switching Inversion of OC stall
36 PID PID control prohibition ON: PID control prohibited
OFF: PID control enabled
6.13
37 PIDN Inversion of PID control prohibition Inversion of PID
48 SCLC Forced local from communication Enabled during communication
ON: Local (Setting of , )
OFF: Communication
5.4
49 SCLCN Inversion of forced local from communication Inversion of SCLC
50 HD Operation hold (hold of 3-wire operation) ON: F (forward run), R: (reverse run) held, 3-wire operation
OFF: Slowdown stop
7.2.1
51 HDN Inversion of operation hold (hold of 3-wire
operation)
Inversion of HD
52 IDC PID integral/differential clear ON: Integral/differential clear, OFF: Clear canceled 6.13
53 IDCN Inversion of PID integral/differential clear Inversion of IDC
54 PIDSW PID characteristics switching ON: Inverted characteristics of selection
OFF: Characteristics of selection
55 PIDSWN Inversion of PID characteristics switching Inversion of PIDSW
