11.3 Extended parameters
Input/output parameters 1
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0100 Low-speed signal
output frequency
Hz 0.1/0.01 0.0- 0.0 6.1.1
0101 Speed reach
setting frequency
Hz 0.1/0.01 0.0- 0.0 6.1.3
0102 Speed reach
detection band
Hz 0.1/.01 0.0- 2.5 6.1.2
6.1.3
0104 Always active
function selection 1
- -
0-153 *6 0 6.3.2
0105 Priority selection
(Both F and R are
ON)
- -
0: Reverse
1: Slowdown Stop
1 6.2.1
0108 Always active
function selection 2
-
-
0-153 *6 70
(SVLOCK)
6.3.2
0109 Analog/logic input
Selection
(VI terminal)
- -
0: Voltage signal input (0-10V)
1: Current signal input (4-20mA)
2: Logic input
3: Voltage signal input (0-5V)
0 6.2.2
6.3.3
6.4.2
7.2.1
7.3
0110 Always active
function selection 3
- - 0-153 *6 6
(ST)
6.3.2
0111 Input terminal
selection 1A (F)
- - 2
(F)
0112 Input terminal
selection 2A (R)
- - 4
(R)
0113 Input terminal
selection 3A (S1)
- - 10
(SS1)
0114 Input terminal
selection 4A (S2)
- -
0-201 *6
12
(SS2)
0115 Input terminal
selection 5 (VI)
- - 8-55 *6 14
(SS3)
6.3.3
6.4.1
7.2.1
0127 Sink/source
switching
- - 0: Sink(Internal power supply),
100: Source,
200: Sink(External power supply)
1-99, 101-199, 201-255: invalid
0
6.3.1
0130 Output terminal
selection 1A (OUT)
- - 68
(Break)
6.3.4
7.2.2
0131 Output terminal
selection 2A (FM)
- - 6
(RCH)
0132 Output terminal
selection 3 (FL)
- - 10
(FL)
0137 Output terminal
selection 1B
(OUT)
- - 255
(always
ON)
0138 Output terminal
selection 2B (FM)
- -
0-255 *7
255
(always
ON)
0: and
and
1: or
and
2: and
or
0139 Output terminal
logic selection
(OUT, FM)
- -
3: or
or
0
*6: Refer to section 11.4 for details about input terminal function.
*7: Refer to section 11.5 for details about output terminal function.
