4-52
4-2 Function Mode
4
Functions
•There's no indication of 2nd control functions on the display. You'll see which one is enabled by
checking whether the terminal is turned on/off.
•Switching the 2nd control using SET during operation does not work until the Inverter stops.
2-step Acceleration/Deceleration Function
This function changes the acceleration/deceleration time during such operations.
A042/A242 Manual torque boost voltage Yes Yes
A043/A243 Manual torque boost frequency Yes Yes
A044/A244 V/f characteristics selection No Yes
A045/A245 Output voltage gain No Yes
A061/A261 Frequency upper limit Yes Yes
A062/A262 Frequency lower limit Yes Yes
A092/A292 Acceleration time 2 Yes Yes
A093/A293 Deceleration time 2 Yes Yes
A094/A294 2-step acceleration/deceleration selection Yes Yes
A095/A295 2-step acceleration frequency Yes Yes
A096/A296 2-step deceleration frequency Yes Yes
b012/b212 Electronic thermal level No Yes
b013/b213 Electronic thermal characteristics selection No Yes
b021/b221 Overload limit selection No Yes
b022/b222 Overload limit level No Yes
b023/b223 Overload limit parameter No Yes
b028/b228 Overload limit source selection No Yes
C001 to C005/
C201 to C205
Multi-function inputs 1 to 5 selection No Yes
C041/C241 Overload warning level No Yes
H003/H203 Motor capacity selection No Yes
H004/H204 Motor pole number selection No Yes
H006/H206 Stabilization parameter No Yes
Parameter No. Function name
Selection
SET SP-SET
Data Symbol Function name Status Description
09 2CH 2-step acceleration/deceleration
ON
Enables the 2-step acceleration/
deceleration time.
OFF
Disables the 2-step acceleration/
deceleration time.
Related functions C001 to C005
Required settings A092, A093, A094 = 00
To Next Page
