Omron 3G3JX User Manual

App-1
Appendix-1 Parameter List
Appendix
AppAppendix
Appendix-1 Parameter List
Monitor Mode (d) / Basic Function Mode (F)
Parameter
No.
Name
Monitor or data range
(Digital Operator)
Default
setting
Changes
during
operation
Unit
Set
value
d001
Output frequency
monitor
0.0 to 400.0 ⎯⎯Hz
d002 Output current monitor 0.0 to 999.9 ⎯⎯A
d003
Rotation direction
monitor
F: Forward
o: Stop
r: Reverse
⎯⎯⎯
d004
PID feedback value
monitor
0.00 to 99.99
100.0 to 999.9
1000. to 9999.
(Enabled when the PID function is selected)
⎯⎯⎯
d005
Multi-function input
monitor
Example)
Terminal
S4, S2: ON
Terminal
S5, S3, S1: OFF
⎯⎯⎯
d006
Multi-function output
monitor
Example)
Terminal P1: ON
Terminal MA: OFF
⎯⎯⎯
d007
Output frequency
monitor
(after conversion)
0.00 to 99.99
100.0 to 999.9
1000. to 9999.
1000 to 3996 (10000 to 39960)
(Output frequency × Conversion factor of
b086)
⎯⎯⎯
d013 Output voltage monitor 0. to 600. ⎯⎯V
d016 Total RUN Time
0. to 9999.
1000 to 9999
⎡100 to ⎡999[h]
⎯⎯h
d017
Power ON time
monitor
0. to 9999.
1000 to 9999
⎡100 to ⎡999[h]
⎯⎯h
d018
Fin temperature
monitor
0.0 to 200.0 °C
d080
Fault frequency
monitor
0. to 9999. ⎯⎯⎯
d081 Fault monitor 1 (Latest)
Error code (condition of occurrence) →
Output frequency [Hz] → Output current [A]
→ Internal DC voltage [V] → RUN time [h] →
ON time [h]
⎯⎯d082 Fault monitor 2
d083 Fault monitor 3
ON
OFF
S5 S4 S3 S2 S1
ON
OFF
MA P1

Omron 3G3JX Specifications

General

Model	3G3JX
Category	Inverter
Control Method	V/f control
Input Frequency	50/60 Hz
Communication Interface	RS-485 (optional)
Operating Temperature	-10 to 50°C
Humidity	20 to 90% RH (non-condensing)
Enclosure Rating	IP20
Input Voltage	200 to 240 V AC
Output Voltage	Three-phase 200 to 240 V AC
Output Frequency	400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat
Communication	RS-485
Braking Unit	Built-in
Power Range	0.1 to 15 kW
Cooling Method	Fan-cooled
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000 m
