1-2
1-1 Functions
1
Overview
Compact Simplified Inverter for Customer's Environment and
Application Demands
îš„Simple Wiring and Easy Installation
The main circuit adopts upper/lower wiring as with a conductor. In addition, the side-by-side
mounting of the Inverters and the built-in zero-phase reactor contribute to space saving in control
panel.
îš„Wide Ranging Capacity and Power Supply
In spite of its compact size, the 3G3JX Inverter provides a wide ranging capacity from 0.2 to 7.5 kW.
Moreover, the three-phase 200 V, three-phase 400 V, and single/three-phase 200 V common types
are made to meet the power supply specifications for use outside Japan.
îš„PID Function
The PID function is featured for the easier control of the fan and pump. It helps to control airflow and
pressure.
îš„Emergency Shutoff Function
Switching the dedicated switch (S8) changes from the multi-function input (input 3) to the
emergency shutoff input. You can directly turn off a motor control power module without operating
the software.
îš„Compliance With All Standards
The 3G3JX Series has achieved compliance with CE and UL/cUL.
îš„The RoHS Directive
The standard model meets the requirements of the RoHS Directive.
îš„Noise and Harmonics Suppression Option
The three-phase models incorporate a zero-phase reactor (radio noise filter) as a standard
specification.
For the single/three-phase common type, optional suppression is available.
When the optional DC reactor is added, the 3G3JX Series will also meet the requirements specified
by the Ministry of Land, Infrastructure, Transport and Tourism of Japan.
îš„Handles a Variety of I/O Signals
The 3G3JX Series can handle a variety of I/O signals for wide-ranging applications.
•Analog voltage input: 0 to 10 V
•Analog current input: 4 to 20 mA
To Next Page
