4-108
4-2 Function Mode
4
Functions
Multi-function Output Terminal ON Delay/OFF Delay
•You can set ON/OFF delay times for each output terminal.
•All output signals immediately turn on/off when the specified conditions are satisfied. Depending
on the selected signal, chattering may occur. In such a case, use this function to hold or delay the
signal.
•Set the parameters for individual output terminals (multi-function output terminals 11 to 15 and the
relay output terminal: six terminals in total). For the output terminals and the corresponding
parameters, refer to the table below.
Input Terminal Response Time
•You can set a sampling time individually for multi-function input terminals 1 to 8 as well as the FW
terminal. This helps remove chattering or other noise.
•If the terminal input becomes unstable because of chattering, increase the set value. The larger
the data value is, the slower the response time. A setting range of 0 to 200 is available, which
corresponds to approx. 2 to 400 ms.
Output terminal ON delay time OFF delay time
11 C130 C131
12 C132 C133
13 C134 C135
14 C136 C137
15 C138 C139
RY (AL*) C140 C141
Function code Item Data Default setting Unit
C130/C132/C134/C136/
C138/C140
Output ON delay
0.0 to 100.0:
Set an ON delay time.
0.0 s
C131/C133/C135/C137/
C139/C141
Output OFF delay
0.0 to 100.0:
Set an OFF delay time.
0.0 s
Parameter No. Function name Data Default setting Unit
C160 to C167
Input terminal response time 1
to 8
0 to 200 (× 2 ms):
Can be set in increments of 1.
1ms
C168 FW terminal response time
