3-24
3-9 Parameter List
3
Operation
Extended Function Mode
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
Basic setting
A001
Frequency reference
selection
00: VR (Digital Operator (FREQ adjuster))
(Enabled when 3G3AX-OP01 is used.)
01: Terminal
02: Digital Operator (F001)
03: RS485 (ModBus communication)
04: Option 1
05: Option 2
06: Pulse train frequency
07: EzSQ (Drive programming)
10: (Math) Operation function result
01 No 
4-10
4-144
A002
RUN command
selection
01: Terminal
02: Digital Operator (F001)
03: RS485 (ModBus communication)
04: Option 1
05: Option 2
01 No  4-11
A003 Base frequency 30 to Maximum frequency [A004] 50
No Hz
4-11
4-112
A203
* 2nd set base
frequency
30 to 2nd maximum frequency [A204] 50
4-11
A303
* 3rd set base
frequency
30 to 3rd maximum frequency [A304] 50
A004 Maximum frequency A003 to 400 50
No Hz 4-12
A204
* 2nd maximum
frequency
A203 to 400 50
A304
* 3rd maximum
frequency
A303 to 400 50
Analog input, Others
A005 O/OI selection
00: [O]/[O2] Switches between O/OI via
terminal AT
01: [O]/[O2] Switches between O/O2 via
terminal AT
02: [O]/VR Switches between O/FREQ
adjuster via terminal AT
(Enabled only when 3G3AX-OP01 is
used)
03: [OI]/VR Switches between OI/FREQ
adjuster via terminal AT
(Enabled only when 3G3AX-OP01 is
used)
04: [O2]/VR Switches between O2/FREQ
adjuster via terminal AT
(Enabled only when 3G3AX-OP01 is
used)
00 No  4-12
A006 O2 selection
00: [O2] only
01: [O/OI-P] auxiliary frequency reference
(not reversible)
02: [O/OI-PM] auxiliary frequency reference
(reversible)
03: [OFF] O2 disabled
03 No 
4-12
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.
