Omron 3G3RX User Manual

3-35
3-9 Parameter List
3
Operation
Others
b034
RUN time/Power ON
time setting
0 to 65535 0 No h 4-52
b035
Rotation direction
limit selection
00: FREE (Forward and Reverse are
enabled)
01: FWD (Only Forward is enabled)
02: REV (Only Reverse is enabled)
00 No  4-52
b036
Reduced voltage
startup selection
0 (Reduced voltage startup time: small) to
255 (Reduced voltage startup time: large)
6No 4-53
b037 Display selection
00: All (Complete display)
01: Utilized (Individual display of functions)
02: User (User setting)
03: Compare (Data comparison display)
04: Basic (Basic display)
00 No  4-53
b038
Initial screen
selection
000 to 202 001 No  4-56
b039
User parameter
automatic setting
function selection
00: OFF (Disabled)
01: ON (Enabled)
00 No  4-57
Torque limit
b040 Torque limit selection
00: 4-quadrant (Four-quadrant separate
setting)
01: TRQ input (Terminal switch)
02: [O] input (Analog input)
03: Option 1
04: Option 2
00 No -
4-57
4-59
b041
Torque limit 1
(Four-quadrant mode
forward power
running)
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
4-57
4-59
b042
Torque limit 2
(Four-quadrant mode
reverse regeneration)
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
4-57
4-59
b043
Torque limit 3
(Four-quadrant mode
reverse power
running)
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
b044
Torque limit 4
(Four-quadrant mode
forward regeneration)
0 to 200 (0.4 to 55 kW)
0 to 180 (75 to 132 kW)
no (Torque limit disabled)
150 No %
b045
Torque LADSTOP
selection
00: OFF (Disabled)
01: ON (Enabled)
00 No  4-59
Others
b046
Reverse rotation
prevention selection
00: OFF (Disabled)
01: ON (Enabled)
00 No  4-59
b049 Dual rate selection
00: CT (Constant torque)
01: VT (Variable torque)
00 No 
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
* 2nd/3rd control is displayed when "SET(08)/SET3(17)" is allocated to one of multi-function inputs from C001
to C008.

Omron 3G3RX Specifications

General

Dimensions	Varies by model
Weight	Varies by model
Series	3G3RX
Power Rating	0.4 kW to 220 kW
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault, Short circuit
Communication Options	RS-485, Modbus, DeviceNet, Profibus, Ethernet
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Humidity	5% to 95% (non-condensing)
Vibration Resistance	5.9 m/s² (0.6G)
Cooling Method	Fan-cooled
