Omron 3G3RX User Manual

7-25
7-3 Options
7
Specifications
Specifications
Reference
Dimensions Weight
Kg
A B2 C2 D E F
AX-RAO00531100-DE 240 150 275 200 110 6 27.0
AX-RAO00401490-DE 300 165 320 200 125 6 44.0
AX-RAO00331760-DE 300 165 320 200 125 6 44.0
AX-RAO00262170-DE 360 - - 300 145 8 70.0
AX-RAO00212600-DE 360 - - 300 145 8 70.0
Voltage
Max. applicable
motor output kW
Reference
Current value
(A)
Inductance
(mH)
200 V class
0.4 AX-RAO11500026-DE 2.6 11.50
0.75 AX-RAO07600042-DE 4.2 7.60
1.5 AX-RAO04100075-DE 7.5 4.10
2.2 AX-RAO03000105-DE 10.5 3.00
3.7 AX-RAO01830160-DE 16.0 1.83
5.5 AX-RAO01150220-DE 22.0 1.15
7.5 AX-RAO00950320-DE 32.0 0.95
11 AX-RAO00630430-DE 43.0 0.63
15 AX-RAO00490640-DE 64.0 0.49
18.5 AX-RAO00390800-DE 80.0 0.39
22 AX-RAO00330950-DE 95.0 0.33
30 AX-RAO00251210-DE 121.0 0.25
37 AX-RAO00191450-DE 145.0 0.19
45 AX-RAO00161820-DE 182.0 0.16
55 AX-RAO00132200-DE 220.0 0.13
400 V clas
0.4 to 1.5 AX-RAO16300038-DE
3.8 16.30
2.2 AX-RAO11800053-DE 5.3 11.80
4.0 AX-RAO07300080-DE
8.0 7.30
5.5 AX-RAO04600110-DE 11.0 4.60
7.5 AX-RAO03600160-DE 16.0 3.60
11 AX-RAO02500220-DE 22.0 2.50
15.0 AX-RAO02000320-DE 32.0 2.00
18.5 AX-RAO01650400-DE 40.0 1.65
22 AX-RAO01300480-DE 48.0 1.30
30 AX-RAO01030580-DE 58.0 1.03
37 AX-RAO00800750-DE 75.0 0.80
45 AX-RAO00680900-DE 90.0 0.68
55 AX-RAO00531100-DE 110.0 0.53
75 AX-RAO00401490-DE 149.0 0.40
90 AX-RAO00331760-DE 176.0 0.33
110 AX-RAO00262170-DE 217.0 0.26
132 AX-RAO00212600-DE 260.0 0.21

Omron 3G3RX Specifications

General

Dimensions	Varies by model
Weight	Varies by model
Series	3G3RX
Power Rating	0.4 kW to 220 kW
Control Method	V/f control, Sensorless vector control
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault, Short circuit
Communication Options	RS-485, Modbus, DeviceNet, Profibus, Ethernet
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Humidity	5% to 95% (non-condensing)
Vibration Resistance	5.9 m/s² (0.6G)
Cooling Method	Fan-cooled
