3-9 Parameter List
3
Operation
d019
Motor temperature
monitor
-020. to 200.0 C4-5
d022
Life assessment
monitor
4-5
d023 Program counter 0 to 1024
d024 Program number 0 to 9999
d025
Drive programming
monitor (UM0)
-2147483647 to 2147483647
d026
Drive programming
monitor (UM1)
-2147483647 to 2147483647
d027
Drive programming
monitor (UM2)
-2147483647 to 2147483647
d028
Pulse counter
monitor
0 to 2147483647 4-6
d029
Position command
monitor
-1073741823 to 1073741823 when HAPR is
selected
-268435456 to 268435456 when APR2 is
selected.
4-6
d030
Current position
monitor
-1073741823 to 1073741823 when HAPR is
selected
-268435456 to 268435456 when APR2 is
selected.
4-6
4-137
d031 Clock Setting Data and Time for the LCD digital operator
d060 Inverter mode 00 to 01
d080
Fault frequency
monitor
0 to 65535 Time 4-6
d081
Fault monitor 1 (Latest)
Error code (condition of occurrence)
Output frequency [Hz] Output current [A]
Internal DC voltage [V]
RUN time [h]
ON time [h]
4-7
d082
Fault monitor 2
4-7
d083
Fault monitor 3
4-7
d084
Fault monitor 4
4-7
d085
Fault monitor 5
4-7
d086
Fault monitor 6
4-7
d090 Warning monitor
Warning code
0 to 385
4-7
d102 DC voltage monitor 0.0 to 999.9 V4-7
d103
Regenerative
braking load rate
monitor
0.0 to 100.0 %4-7
d104
Electronic thermal
monitor
0.0 to 100.0 %4-7
Parameter
No.
Function name Monitor or data range
Default
setting
Changes
during
operation
Unit Page
MONITOR-A M1-STOP ALL
d022 Life(C/F)
LL
H001 00:OFF
1
2
1: Main circuit board capacitor service life
2: Cooling fan rpm reduction
To Next Page
