5-2-4 Nomenclature
The following figure gives the names of the parts of the DST1-MD16SL-1
• Refer to 4-2 Indicators for information on the LED indicators.
• Refer to 2-4 Connecting the Communications Connector for information
on the DeviceNet communications connector.
• Refer to 5-2-5 Internal Circuits and Terminal Arrangement for information
on the terminal blocks.
5-2-5 Internal Circuits and Terminal Arrangement
The following figure shows the internal circuits of the DST1-MD16SL-1.
LED indicators
DeviceNet
communications
connector
Node address switches
Terminal blocks
V0
G0
V0
G0
IN1
T1
IN0
T0
IN3
T1
IN2
T0
IN5
T1
IN4
T0
IN7
T3
IN6
T2
V1
G1
V1
G1
OUT
1
G1
OUT
0
G1
OUT
3
G1
OUT
2
G1
OUT
5
G1
OUT
4
G1
OUT
7
G1
OUT
6
G1
CAN
H
V−
V+
CAN
L
12345678910
11 12 13 14 15 16 17 18 19 20
21 22 23 24 25 26 27 28 29 30
31 32 33 34 35 36 37 38 39 40
Safety input circuits
(current sinking)
DC-DC
converter
(non-isolated)
DeviceNet
physical
layer
I/O power
supply
circuit
Internal circuits
Test output
circuits
(current sourcing)
I/O power
supply
circuit
Safety output circuit
(current sourcing)
Shield
