Omron DST1-ID12SL-1 User Manual

101
DST1-MRD08SL-1 Section 5-3
5-3 DST1-MRD08SL-1
5-3-1 Safety Input Specifications
The following table gives the safety input specifications for the DST1-
MRD08SL-1.
5-3-2 Test Output Specifications
The following table gives the test output specifications for the DST1-
MRD08SL-1.
5-3-3 Safety Output Specifications for Relay Outputs
The following table gives the safety output specifications for the DST1-
MRD08SL-1.
Note This value applies to a switching frequency of 300 operations/min.
Item Specifications
Input type Sinking input (PNP)
ON voltage 11 VDC min. between each input termi-
nal and G0
OFF voltage 5 VDC max. between each input termi-
nal and G0
OFF current 1 mA max.
Input current 6 mA
Item Specifications
Output type Sourcing output (PNP)
Rated output current 0.7 A
Residual voltage 1.2 V max. between each output termi-
nal and V0
Leakage current 0.1 mA max.
Item Specifications
Relays G7SA-2A2B
EN50205 Class A
Failure rate P level (See note.) (Refer-
ence value)
1 mA at 5 VDC
Rated load for a resistive load 240 VAC: 2 A
30 VDC: 2 A
Durability Mechanical life
expectancy
5,000,000 operations min.
(at approx. 7,200 operations/h)
Electrical life
expectancy
100,000 operations min.
(at rated load and approx. 1,800 operations/h)
