17
Logic Functions Section 1-5
Output Monitors
The outputs monitors indicated the actual ON/OFF status of the safety out-
puts.
1-5 Logic Functions
The DST1-XD0808SL-1 supports logic functions.
1-5-1 Overview
Safety logic control can be easily performed by setting a combination of I/O
data from local I/O terminals and remote I/O data from a Standard Master or
Safety Master with the logic operations supported by the DST1-XD0808SL-1.
In addition, the safety status can be monitored from standard controls by
using the safety output terminals as additional outputs and outputting data
such as error information.
Note (1) Refer to the NE0A Series Safety Network Controller Operation Manual
(Cat. No. Z916) for details on functions and setting methods.
(2) Some NE0A-SCPU01 functions are not supported by the DST1-
XD0808SL1. Refer to 1-5-2 Restrictions on the DST1-XD0808SL-1 for
details
1-5-2 Restrictions on the DST1-XD0808SL-1
NE0A Series Safety Network Controller Operation Manual Restrictions on the DST1-XD0808SL-1
Section Item
6-3-1 Starting the Safety Wizard Network settings cannot be made.
6-3-4 Setting Networks Network settings cannot be made.
6-4-1 Safety Input Evaluation Enable switches cannot be set.
User mode switches cannot be set.
Input ON-delay and OFF-delay times must be set from 0
to 126 ms (in 6-ms increments).
6-4-2 Input Condition Operations Refer to 1-5-3 Parameters That Can Be Set for the input
condition signals that can be set.
6-4-3 Reset Operation Refer to 1-5-3 Parameters That Can Be Set for the reset
condition signals that can be set.
6-4-4 Output Condition Operations Refer to 1-5-3 Parameters That Can Be Set for the output
condition signals that can be set.
6-4-5 Welding Check (EDM: External Device Moni-
toring) Operation
Refer to 1-5-3 Parameters That Can Be Set for the feed-
back signals that can be set.
6-4-6 Safety Output Evaluation Refer to 1-5-3 Parameters That Can Be Set for the addi-
tional outputs that can be set.
