106 LD Cart Transporter User's Manual 14766-000 Rev H
6.3 î ±Standard Platform Connections
Callout Connection Type Description
E VGA HDB15F Reserved
F USB x 3 USB Type A Reserved
G LIDAR HDB26M Safety Scanning Laser
H Right Motor HDB26F NOTE:The Right and Left Motor connectors use
the same type of plug. Take care not to reverse
them.
J Left Motor HDB26F
K Battery Power Mini-Fit Sr.,
3-pin
Battery VDC; connects to battery
L Bumper
Switches
Mini-Fit 2 x 4 This connection is not used with a LD Platform Cart
Transporter.
M Speakers Mini-Fit 2 x 2 Drives built-in speakers
N Battery
Comm.
Mini-Fit 2 x 3 Battery communication/control
Core Internal Data Pinouts
Wheel Lights (Light Discs)
Connector type DB9F
Use Motion and status indicator Light Discs on the platform sides
Designation
Pin No. Hardware Software Notes
1, 2 CANL_A CAN Communication differential pair
3, 4 GND Direct GND
5 SHIELD GND Bead filter to GND
6, 7 CANH_A CAN Communication differential pair
8, 9 SW_12V_WHEEL WheelLight_Power 12 V @ 1 A Max (switched in SW)
NOTE: Sonar 1 is covered at the end of Core, Upper Rear.
