Omron LD-105CT User Manual

Chapter 11: Technical Specifications
11.1 Dimension Drawings
431
48
626.6
1306.7
1393.2
144.6
96
699
894
84.0
195.0
133.1
Ø101.6
504.9
38
x2
500
416.0
1073.3
Figure 11-1. Overall LD Platform Cart Transporter Dimensions (units are mm)
10x Ø6.6
A
88.9
190.5
68.6
0
41.9
188 334
479.8 502.7
24.1
429
453
153.4
299.5
0
Figure 11-2. Coupling Plate Dimensions, Arms Removed, (A) Through hole (units are mm)
14766-000 Rev H LD Cart Transporter User's Manual 187
