Chapter 10: Maintenance
This chapter covers periodic maintenance and user-serviceable parts replacement for the LD
Platform Cart Transporter.
Figure 10-1. Major LD Platform Cart Transporter System Parts, with Acuity Camera
Callout Description Callout Description
A Operator Panel G Rear-facing Laser, Guard
B Side Lasers, Guard x2 H Light Disc x2
C Laser Support Tube x2 J Rear Sonar
D Brace x2 K Battery Cover
E Navigation Laser L HMI post
F Low Front Laser
14766-000 Rev H LD Cart Transporter User's Manual 145
