Chapter 11: Technical Specifications
Description Specification
Rating
IP Rating IP20
Cleanroom rating Fed Class 100, ISO Class 5
Suspension
Drive wheels 2 grey non-marking foam-filled rubber
Wheel diameter 200 x 50 mm nominal
Brakes 2 (one each axle)
Steering Differential
Passive Casters 2 front, 2 rear, spring-loaded
Caster diameter 75 mm nominal
LD Platform Cart Transporter Performance
Description Specification
Performance
Max payload LD-105CT: 105 kg (231 lb)
LD-130CT: 130 kg (287 lb)
Run-time 15 h continuous, approx.
Swing radius Platform or Platform and Cart:
698.5 mm
Turn radius 0 mm
Translational speed, max LD-105CT: 1350 mm/s (53.1 inches/s)
LD-130CT: 900 mm/s (35.4 inches/s)
Traversable step 5 mm with cart, 130 kg
Traversable gap 5 mm with cart, 130 kg
CAUTION: PROPERTYDAMAGERISK
The LD Platform Cart Transporter with a cart is capable of driving
over a gap or step of 5 mm (0.2 inch) at a speed of 250 mm/s, but
this should not be regarded as normal use. Regular driving over
such gaps or steps will shorten the lifespan of the drivetrain com-
ponents.
Minimum floor flatness F
F
25 (based on the ACI 117 standard)
NOTE: ACI 117 is the American Concrete Institute’s standard for
concrete floors. F
F
is flatness, F
L
is the level. Higher F
F
numbers
represent flatter floors. F
F
25 is a fairly lenient specification.
14766-000 Rev H LD Cart Transporter User's Manual 189
