9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
ENGINE COOLING ASSEMBLY
REF
DESCRIPTION TORQUE/NOTE
q
Washer: 6.15 x 12 x 1.0 NA
w
Bleed Fastener: M6 x 1.0 x 13 6 ft-lbs (8 Nm)
e
Fastener: M6 x 1.0 x 20
7 ft-lbs (10 Nm)
r
Oil Cooler
NA
t
Oil Cooler Outlet Hose
NA
y
Water Pump NA
u
Coolant Hose Clamp 35 in-lbs (4 Nm)
i
Water Pump Fastener: M6 x 1.0 x 35 7 ft-lbs (10 Nm)
o
Retention Clip
NA
a
Engine Outlet Hose
NA
s
Retention Clip
NA
d
Oil Cooler Inlet Hose
NA
f
Thermostat NA
ENGINE / COOLING / EXHAUST
