9. Allow the lower A-arm to drop and remove the upper
A-arm by maneuvering the rear shock and stabilizer
link out.
REAR UPPER A-ARM INSTALLATION
WARNING
The locking agent on the existing bolts was destroyed
during removal. DO NOT reuse old hardware. Serious
injury or death could result if fasteners come loose
during operation.
1. Install the upper A-arm onto the frame by
maneuvering the shock and stabilizer link into the A-
arm. Torque new fasteners to specification.
TORQUE
Rear A-Arm to Frame Fastener:
81 ft-lbs (110 N·m)
2. Attach the upper A-arm to the bearing carrier. Torque
new fastener to specification.
TORQUE
Rear Upper A-Arm to Bearing Carrier Fastener:
44 ft-lbs (60 N·m)
3. Attach the lower portion of the rear shock to the rear
lower A-arm. Torque new fastener to specification.
TORQUE
Shock Mounting Bolts:
44 ft-lbs (60 N·m)
4. Attach the lower stabilizer bar link to the lower A-arm.
Torque new fastener to specification.
5. Attach the stabilizer bar to the frame. Torque
fasteners to specification.
TORQUE
Stabilizer Bar Fasteners:
17 lb-ft (23 Nm)
6. Install wheel and torque wheel nuts to specification.
TORQUE
Wheel Nuts (Steel): 60 lb-ft (81 Nm)
Wheel Nuts (Aluminum): 120 lb-ft (163 Nm)
WARNING
Upon A-arm installation completion, test vehicle at low
speeds before putting into service.
