1.24
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
GENERAL SPECIFICATIONS
RANGER 1000 CREW
Length
152 in / 385 cm
Width 62.5 in / 159 cm
Height
75 in / 191 cm
Wheel Base 113 in / 287 cm
Ground Clearance 12 in / 30.5 cm
Dry Weight 1786 lbs / 810.1 kg
Gross Vehicle Weight 3750 lbs / 1701 kg
Cargo Box Capacity 1000 lbs / 454 kg
600 lbs / 272 kg (CA Models)
Cargo Box Dimensions
(Inside)
36.75 x 54.25 x 12.5 in
(93.3 x 137.8 x 13.75 cm)
Maximum Weight Capacity
(Payload)
1750 lbs / 794 kg
1350 lbs / 612 kg (CA Models)
(Includes riders, cargo and accessories)
Hitch Towing Capacity 2500 lbs / 1134 kg
Hitch Tongue Capacity 150 lbs / 68 kg
ENGINE
RANGER 1000 CREW
Platform
4-Stroke, SOHC, Twin Cylinder
Engine Displacement 61 ci (999 cc)
Number of Cylinders
2
Bore & Stroke 93 mm x 73.5 mm
Compression Ratio
10.5:1
Engine Idle Speed
1250 ± 100 RPM
Engine Max Speed
7000 RPM
Valve Clearance (Int) 0.006 in (0.15 mm) ± 0.002 (0.05 mm)
Valve Clearance (Exh) 0.010 in (0.25 mm) ± 0.002 (0.05 mm)
Engine Hot Light
Instrument Cluster Indicator
Lubrication
Wet Sump
Oil Requirements PS-4 5W-50 Full Synthetic or PS-4 10W-50 Extreme Duty Full Synthetic
Oil Capacity 2.5 Qt. (2.4 L)
Coolant Capacity 5.0 Qt (4.75 L)
GENERAL INFORMATION
