7.6
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
8. While holding the upper jam nut
y
use a crows foot
to tighten the lower jam nut
t
. Torque to
specification.
IMPORTANT
When setting torque using a crows foot, the socket
must be at a 90° angle to the torque wrench as shown.
TORQUE
Lower Jam Nut:
13 ft-lbs (18 N·m)
9. After adjustment verify there is no contact with the
dash in both Park/High. If the shifter is still contacting
the dash, repeat the adjustment procedure until there
is no contact with the dash.
10.Reinstall the rubber bezel.
11. With the engine off, check the following:
• Shifter fully engages all gears.
• Dash is not moving when shifting into Park/High
TRANSMISSION
