BODY / STEERING / SUSPENSION
5.9
STRUT ASSEMBLY
Nut - 15 ft. lbs. (21 Nm)
Washer
Spacer Rubber
Upper Pivot Ball
Lower Pivot Ball
Spacer Nut
Spring Retainer
Spring
Strut Bumper
Strut Cartridge
Spring Retainer Washer
Strut Housing
Clamp
Ball Joint
Grease Fitting
Washer
Lock Nut
Bolt
Washer
Spindle
15 ft. lbs. (21 Nm)
