3.1Installationchecklist
Installationincludesthefollowingactivities:
InstallationTask
1Planyoursystem.
2
Obtainallrequiredequipmentandtools.
3
Siteallequipment.
4Routeallcables.
5
Drillcableandmountingholes.
6Makeallconnectionsintoequipment.
7
Secureallequipmentinplace.
8Poweronandtestthesystem.
3.2Partssupplied–DV,DVS,andPro
variants
Thepartssuppliedwithyourproductareshown
below.
D13178-1
1
9
10
16
6
7
8
2
3
4
5
17
x3
x3
x3
x3
11
18
12 13 14 15
1.Displayunit
2.Lockingcollar
3.Pivotball
4.M6Hexbolt
5.Displaybracketbase
6.3xM5pozi-drivebolt
7.3xM5washer
8.3xM5lockingnut
9.Ratchetarm
10.Mountingbracket
11.M5Hexratchetbolt
12.Ratchetplate
13.Compressionwasher
14.M5washer
15.M5lockingnut
16.3xSelftappingscrews
17.Documentation
18.Transducerwithcombinedpowercable
20
Dragony-4/Dragony-5/WiFish
