5.3Connectingthecable-DV,DVS,
ProandWi-Fish
TM
Theunithasacombinedpowerandtransducer
cablethatisattachedtothetransducer.
D13190-1
2
4
5
3
1
12 V dc
1.Connectthetransducer/powerconnectorto
therearoftheunitandsecureusingthelocking
collar.
2.Thedrainwireshouldbeconnectedtothevessel
RFgroundpoint.Ifyourvesselhasnoground
pointconnecttothenegativesideofthevessel’s
powersupply.
3.TheNegativewiremustbeconnectedtothe
negativesideofthe12Vdcpowersupply.
4.Afuseholder(notsupplied)MUSTbettedtothe
positivewireusinga5Ainlinefuse.
5.Thepositivewiremustbeconnectedtothe
positivesideofthe12Vdcpowersupply.
5.4Connectingthepowercable-5M
D13193-1
2
4
5
3
1
12 V dc
1.Connectthepowercabletotherearofthedisplay
andsecureusingthelockingcollar.
2.Thedrainwireshouldbeconnectedtothevessel
RFgroundpoint.Ifyourvesselhasnoground
pointconnecttothenegativesideofthevessel’s
powersupply.
3.TheNegativewiremustbeconnectedtothe
negativesideofthe12Vdcpowersupply.
4.Afuseholderand5Ainlinefuse(notsupplied)
MUSTbettedtothepositivewire.
5.Thepositivewiremustbeconnectedtothe
positivesideofthe12Vdcpowersupply.
Connectingthecabletothedisplay
00
0
00
0
D12779-2
2
1
1.Unlocked
2.Locked
1.Ensurethelockingcollarisintheunlocked
position.
2.Ensurethatthecableconnectorisorientated
sothatthenotchlinesupwiththeguideinthe
connector.
3.Pushthecableconnectorallthewayintothe
displayconnector.
4.Rotatethelockingcollarclockwiseuntilinthe
lockedposition(2clicks).
Warning:12Voltdconly
Thisproductmustonlybeconnectedtoa
12voltdcpowersource.
38
Dragony-4/Dragony-5/WiFish
