Note:
•Thesuitablefuseratingforthethermalbreaker
isdependentonthenumberofdevicesyouare
connecting.Ifindoubtconsultanauthorized
Raymarinedealer.
•Yourproduct’spowercablemayhavetted
in-linefuse,ifnotthenyoucanaddanin-line
fusetothepositivewireofyourproductspower
connection.
5.5Extensioncableconnection
Anoptionalextensioncablecanbeusedtoextend
thedistancefromthetransducertotheunitbyup
to4m(13.1ft).
12 V dc
D13241-1
2
1
3
1.Existingcable.
2.Extensioncable(connectedtothevessel’s
powersupplyandtotheexistingcable.
3.Isolatedpowersupplywiresonexisting
transducercable.
Note:
•Only1extensioncableshouldbeusedper
installation.
•Thelengthofthepowersupplywiresonthe
extensioncableis2m(6.6ft).
Maximumtransducercablelength
Themaximumcablelengthfromthetransducerto
theunitisshownbelow.
CPT-DV8m(26.2ft.)—4m(13.1ft.)
suppliedcable+4m(13.1ft.)
extensioncable
CPT-DVS10m(32.8ft.)—6m(19.7
ft.)suppliedcable+4m(13.1
ft.)extensioncable
Note:Extendingthetransducercablefurtherthan
themaximumstateddistancewillcausepoor
performance.
40
Dragony-4/Dragony-5/WiFish
