Raymarine Wi-Fish User Manual

6.4Wi-Fish
TM
initialsetup
OncetheWi-Fish
TM
unitisinstalledandconnected
toyoursmartdevice,whichisrunningthelatest
versionoftheWi-Fish
TM
app,itisrecommended
thatthefollowingtasksarecompleted:
•Congureunitsofmeasurefordepthand
temperaturereadings
•Setatransduceroffset
•Viewtheapp’sHelppages
•Familiarizeyourselfwiththeproductusing
SimulatorMode.
TheseoptionsareavailableintheWi-Fish
TM
mobile
app’sMoremenuwhichincludesthefollowing
settings:
•Settings
–Transducerdepthoffset
–Depthunits
–Temperatureunits
–Simulator
•Help
•About
.
6.5DepthOffset
Depthsaremeasuredfromthetransducertothesea
bed,butyoucanapplyanoffsetvaluetothedepth
data,sothatthedisplayeddepthreadingrepresents
thedepthtotheseabedfromeitherthekeelorthe
waterline.
Beforeattemptingtosetawaterlineorkeel
offset,ndouttheverticalseparationbetweenthe
transducerandeitherthewaterlineorthebottomof
thekeelonyourvessel,asappropriate.Thensetthe
appropriatedepthoffsetvalue.
D9343--2
1 2 3
1
Waterlineoffset
2
Transducer/Zerooffset
3
Keeloffset
Ifanoffsetisnotapplied,displayeddepthreadings
representthedistancefromthetransducertothe
seabed.
Assigningatransducerdepthoffset—
Wi-Fish
TM
app
Followthestepsbelowtoassignadepthoffsetvalue
toyourdepthreadings.
WiththeWi-Fish
TM
mobileappconnectedand
runningonyoursmartdevice:
1.SelecttheMoreicon(threeverticaldots).
2.SelectSettings.
3.SelectTransducerDepthOffset.
4.Adjustthedepthoffsettotherequiredvalue.
44
