Note:

•Itmaynotalwaysbepossibletoobtaindepth

readingsathigherspeedsduetoairbubbles

passingunderthetransducer.

•Itmaybenecessarytomakeseveral

adjustmentstothetransducerbeforeobtaining

optimumperformance.

•Ifthetransducerrequiresrepositioningensure

alloldholesarelledwithmarinegradesealant.

4.6Finalizingthetransducermounting

Onceyouhaveachievedoptimumperformanceat

thedesiredvesselspeedsthetransducermustbe

lockedintopositiontocompletetheinstallation.

D13197-1

1.Drillthelockingholelocationtakingcarenotto

damagethemountingbracket.

2.Fillthelockingholewithmarinegradesealant.

3.Securethetransducerandbracketbyfully

tighteningall3mountingscrews.

4.Securetheratchetarmbolt,bytighteninguntil

thecompressionwasheriscompressedandthen

addanother1/4turn.Ifthetransducerkicksupat

speedthentightenfurther.

Note:Overtighteningmaycausedamage.

Mounting
