5.1Generalcablingguidance
Cabletypesandlength
Itisimportanttousecablesoftheappropriatetype
andlength
•Unlessotherwisestateduseonlystandardcables
ofthecorrecttype,suppliedbyRaymarine.
•Ensurethatanynon-Raymarinecablesareofthe
correctqualityandgauge.Forexample,longer
powercablerunsmayrequirelargerwiregauges
tominimizevoltagedropalongtherun.
Routingcables
Cablesmustberoutedcorrectly,tomaximize
performanceandprolongcablelife.
•DoNOTbendcablesexcessively.Wherever
possible,ensureaminimumbenddiameterof200
mm(8in)/minimumbendradiusof100mm(4in).
100 mm (4 in)
200 mm (8 in)
•Protectallcablesfromphysicaldamageand
exposuretoheat.Usetrunkingorconduitwhere
possible.DoNOTruncablesthroughbilgesor
doorways,orclosetomovingorhotobjects.
•Securecablesinplaceusingtie-wrapsorlacing
twine.Coilanyextracableandtieitoutoftheway.
•Whereacablepassesthroughanexposed
bulkheadordeckhead,useasuitablewatertight
feed-through.
•DoNOTruncablesneartoenginesoruorescent
lights.
Alwaysroutedatacablesasfarawayaspossible
from:
•otherequipmentandcables,
•highcurrentcarryingacanddcpowerlines,
•antennae.
Strainrelief
Ensureadequatestrainreliefisprovided.Protect
connectorsfromstrainandensuretheywillnotpull
outunderextremeseaconditions.
Cableshielding
Ensurethatthecableisproperlyshieldedthatthe
cableshieldingisintact(e.g.hasn’tbeenscrapedoff
bybeingsqueezedthroughatightarea).
5.2Connectionsoverview
Dragony-4/Dragony-5,Wi-Fish
TM
productsand
theCPT-DVandCPT-DVSincludeconnectorswitha
3keywayguide.Dependingondateofmanufacture
Dragony-6,Dragony-7productsandCPT-60/
CPT-70/CPT-80transducersareavailablewith1
keywayguide(Legacy)or3keywayguide(Updated).
Adaptorcablescanbeusedtoconnect1keyway
connectorsto3keywayconnectors.
Rearconnector/Lockingcollar
ConnectorDescription
Unit/
Display
Compatible
transducer
Red–1
keyway
•Legacy
Dragon-
y-6
•Legacy
Dragon-
y-7
•Legacy
CPT-60
•Legacy
CPT-70
•Legacy
CPT-80
Green–3
keyway
•DVS
•Pro
•Updated
Dragon-
y-6
•Updated
Dragon-
y-7
•CPT-DVS
•Updated
CPT-60
•Updated
CPT-70
•Updated
CPT-80
Yellow–3
keyway
•DV
•Wi-Fish
TM
•CPT-DV
Black–3
keyway
•5M
•N/A–5
Mpower
connector
36
Dragony-4/Dragony-5/WiFish
