Missing Image Area
Even if you place originals in the ADF or on the exposure glass correctly, margin of a few millimeters on
all four sides of the original might not be copied.
• Type 1 and 2
1. 0.5 - 4.0 mm (0.02 - 0.16 inch)
2. 0.5 - 6.0 mm (0.02 - 0.24 inch)
3. 0.5 - 4.0 mm (0.02 - 0.16 inch)
4. 4.2 ± 1.5. mm (0.17 ± 0.06 inch)
• Type 3 and 4
1. 0.5 - 4.0 mm (0.02 - 0.16 inch)
2. 0.5 - 6.0 mm (0.02 - 0.24 inch)
3. 0.5 - 4.0 mm (0.02 - 0.16 inch)
4. 5.2 ±1.5. mm (0.2 ± 0.06 inch)
• With the Type 3 and 4, the width of the missing leading-edge image area for paper heavier than 82
g/m
2
is 4.2 ± 1.5 mm (0.17 ± 0.06 inch).
Originals
27
