1. 2nd scanner
2. Exposure lamp
3. 1st scanner
4. Original length sensor
5. Lens
6. Scanner motor
7. SBU board
8. Exit roller
9. Fusing hot roller
10. Fusing pressure roller
11. Cleaning unit
12. OPC drum
13. Transfer roller
14. Development roller
15. ID sensor
16. Registration roller
17. Feed roller
18. Separation roller
19. Pick-up roller
20. Optional tray heater
21. Polygon mirror motor
22. Laser unit
23. Toner supply bottle holder
24. Drum charge roller
25. Scanner home position sensor
Overview
21
1
