Paper Feed Unit PB3130 (D580)
Accessory Check
Check the quantity and condition of the accessories against the following list.
No. Description Q'ty
1 Screw – M4 x 10 2
2 Screw with Spring Washer – M4 x 10 1
3 Securing Bracket 2
Installation Procedure
• Unplug the machine power cord before starting the following procedure.
• The handles of the main machine for lifting must be inserted inside the machine and locked unless
these handles are used for the installation or relocation of the main machine.
• You need two or more persons to lift the copier. The copier is highly unstable when lifted by one
person, and may cause human injury or property damage.
2. Installation
52
