• Do not touch the drum surface with bare hands.
Pick-off Pawls
1. Remove the PCU. ( p.210 "PCU Removal")
2. Hold the pawl [A] by its sides, pull it down and slowly twist it away from the PCU.
OPC Drum
1. Remove the PCU. ( p.210 "PCU Removal")
Photoconductor Unit (PCU)
211
4
