Symbol What it means
C-ring
Harness clamp
FFC Flat Film Connector
The notations "SEF" and "LEF" describe the direction of paper feed. The arrows indicate the direction of
paper feed.
In this manual "Horizontal" means the "Main Scan Direction" and "Vertical" means the "Sub Scan
Direction" relative to the paper feed direction.
4
