49Publication 2711C-QS001F-EN-P - November 2010 49
Chapter
6
Create the Motor Status Screen
Introduction
In this chapter, you will create the Motor Status screen of the application.
Before You Begin
• Review the sample application.
• Connect your terminal to your computer and launch the PanelView Explorer software.
• Configure browser settings.
• Open a new application.
• Configure runtime communication settings for the application.
• Create tags for the application.
What You Need
• Tags to assign to objects. These tags were defined in Chapter 5, Create Tags.
Topic Page
Change the Screen Name 51
Change the Grid Attributes 52
Create the Start Motor Push Button 52
Create the Stop Motor Push Button 54
Create the Motor Speed Screen Button 56
Create a Goto Config Button 58
Create the Motor Control List Selector 59
Create the Motor Status Indicators 64
Save the Motor Status Screen 70
