SATO CL6NX Service Manual

2 Operation and Configuration
11
CL4NX/CL6NX Service Manual
2.2 Tools Menu Tree Structure
The table below outlines only the tree structure for the Service menu in the Tools menu. Refer to the
tree structure to understand where information is located in the Tools menu. Click on the items in blue to
link directly to the details of the selected items.
Tools Submenus
Test Print
HEX-Dump
Reset
Profiles
Service RFID RFID Mode
Module
Region
Inventory Check
Inventory Timeout
Verify
PREND Type 3/4
Hide Help Videos
Wi-Fi Region
Reset Select Data
Data & Settings
Settings
Counters
Clone
Maintenance Printer Serial
Offset
Pitch
Certificates
Startup Guide

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
