Appendix B Control Panel and Touch Screen
B - 16 Instructions for Use
Specialty Controls
UD (User-Defined)
Activates the function assigned to this control.
Use the system configuration menu to assign functionality to this control.
System Config > Footswitch and UD Key
Pointer
Press the pointer control to enable text entry or access to the controls on the image screen or
the thumbnails on the right side of the image screen.
Note: If a tool is activated and the trackball pointer (cursor) is not visible, press POINTER to
redisplay the pointer.
Forward/Backward
 During an eSieScan protocol or a stress echo protocol, pauses or resumes the protocol
when you press the control.
 Activates the next or previous page of images when you rotate the control.
