Siemens MICROMASTER 440 User Manual

Issue 10/06 3 Functions
MICROMASTER 440 Operating Instructions
6SE6400-5AW00-0BP0
177
3.11.1.1 PID motorized potentiometer (PID-MOP)
Parameter range: P2231 – r2250
Warnings -
Faults -
Function chart number: FP3400
The PID controller has a PID motorized potentiometer which can be separately
adjusted. The functionality is identical with the motorized potentiometer (refer to
Section 3.9), whereby the PID parameters are emulated in the range from P2231 –
r2250 (refer to the comparison
→ Table 3-26).
Table 3-26 Correspondence between the parameters
PID motorized potentiometer Motorized potentiometer
P2231[3] Setpoint memory of PID-MOP P1031[3] Setpoint memory of the MOP
P2232 Inhibit rev. direct. of PID-MOP P1032 Inhibit reverse direction of MOP
P2235[3] BI: Enable PID-MOP (UP-CMD) P1035[3] BI: Enable MOP (UP command)
P2236[3] BI: Enable PID-MOP (DOWN-
CMD)
P1036[3] BI: Enable MOP (DOWN
command)
P2240[3] Setpoint of PID-MOP P1040[3] Setpoint of the MOP
r2250 CO: Output setpoint of PID-MOP r1050 CO: Act. output freq. of the MOP

Siemens MICROMASTER 440 Specifications

General

Power Range	0.12 kW to 250 kW
Output Voltage	0 V to Input Voltage
Output Frequency	0 Hz to 650 Hz
Control Modes	Vector control
Overload Capability	150% for 60 seconds
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	PROFIBUS, DeviceNet, CANopen, Modbus RTU
Enclosure Rating	IP20
Ambient Temperature	-10°C to +50°C
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
