3.5 Commissioning
A differentiation is made between the following scenarios when commissioning
MICROMASTER:
¾ 50/60 Hz changeover ¾ Quick commissioning
¾ Motor data identification ¾ Calculating the motor / control data
¾ Series commissioning ¾ Commissioning the application
Start commissioning
Complete
parameter list
of a commissioning
available
?
End of commissioning
Quick commissioning
Section 3.5.3
Is the moment
of inertia of the motor
and load known
?
Series commissioning
Section 3.5.7
Motor
equivalent
circuit diagram data
known
?
Commissioning the application
Section 3.5.6
P0341 = ?
P0342 = ?
P0344 = ?
P0340 = 1
yes
no
yes
no
yes
no
Enter motor equivalent
circuit diagram data
Section 3.5.4
Motor data identification
Section 3.5.5
Carry-out checklist
NEMA motor
60 Hz / hp ?
Section 3.5.2
50/60 Hz setting
Section 3.5.1
yes
no
Fig. 3-20 Procedure when commissioning
