3.2 Assignment of cyclic receive and send data for predefined control functions
SIMOCODE pro - Communication
132 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.2.5
Star-delta starter
Table 3- 8 Assignment of cyclic receive / send data, star/delta starter
Cyclic receive data
Bit 0.0 Not connected
Bit 0.1
Device parameters → Motor control → Control stations → PLC/PCS [DP] → OFF
Bit 0.2 Device parameters → Motor control → Control stations → PLC/PCS [DP] → ON
Bit 0.3
Further function blocks → Standard functions → Test / Reset → Test1 - Input
Bit 0.4
Further function blocks → Standard functions → Emergency start → Emergency start - Input
Bit 0.5
Device parameters → Motor control → Control stations → Mode selector S1
Bit 0.6
Further function blocks → Standard functions → Test / Reset → Reset 1 - Input
Bit 0.7
Not connected
Bit 1.0
Not connected
Bit 1.1
Not connected
Bit 1.2
Not connected
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 *) (analog value)
Not connected
Cycl. send data
Bit 0.0
Not connected
Bit 0.1 Status - Off
Bit 0.2
Status - ON
Bit 0.3
Event - Prewarning overload (I>115 %)
Bit 0.4
Status - Change-over pause active
Bit 0.5
Status - Remote mode
Bit 0.6
Status - General fault
Bit 0.7 Status - general warning
Bit 1.0
Not connected
Bit 1.1
Not connected
Bit 1.2
Not connected
Bit 1.3
Not connected
Bit 1.4
Not connected
Bit 1.5
Not connected
Bit 1.6
Not connected
Bit 1.7
Not connected
Byte 2/3 (analog value)
Maximum current I_max
Byte 4/5 *) (analog value)
Not connected
Byte 6/7 *) (analog value)
Not connected
Byte 8/9 *) (analog value)
Not connected
*) for SIMOCODE pro V / pro S, basic type 1 only
