Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
269
3.4.2.15
Data record 135 - Extended device parameters 2
Table 3- 66 Data record 135 - ExtendedPlus device parameters 2
Byte.Bit
Designation (PRM group)
Type
Range
Unit
Default
Note
Information
0.0
Coordination
Byte[4]
4.0
Part - DI byte parameters
4.0
Truth table 10 3I/1O - Input 1
DI byte
0 - 255
0
5.0 Truth table 10 3I/1O - Input 2 DI byte 0 - 255 0
6.0
Truth table 10 3I/1O - Input 3
DI byte
0 - 255
0
7.0
Truth table 11 3I/1O - Input 1
DI byte
0 - 255
0
8.0
Truth table 11 3I/1O - Input 2
DI byte
0 - 255
0
9.0
Truth table 11 3I/1O - Input 3
DI byte
0 - 255
0
10.0
Timer 5 input
DI byte
0 - 255
0
11.0
Timer 5 reset
DI byte
0 - 255
0
12.0
Timer 6 input
DI byte
0 - 255
0
13.0
Timer 6 reset
DI byte
0 - 255
0
14.0
Counter 5 input +
DI byte
0 - 255
0
15.0
Counter 5 input -
DI byte
0 - 255
0
16.0
Counter 5 reset
DI byte
0 - 255
0
17.0
Counter 6 input +
DI byte
0 - 255
0
18.0
Counter 6 input -
DI byte
0 - 255
0
19.0
Counter 6 reset
DI byte
0 - 255
0
20.0
Signal conditioning 5 input
DI byte
0 - 255
0
21.0
Signal conditioning 5 reset
DI byte
0 - 255
0
22.0
Signal conditioning 6 input
DI byte
0 - 255
0
23.0
Signal conditioning 6 reset
DI byte
0 - 255
0
24.0 Analog multiplexer S1 DI byte 0 - 255 0
25.0
Analog multiplexer S2
DI byte
0 - 255
0
26.0 Reserved
27.0
Reserved
28.0
Reserved
29.0
Reserved
30.0
Reserved
31.0
Reserved
32.0
Reserved
33.0
Reserved
34.0
Reserved
35.0
Reserved
36.0
Reserved
37.0
Reserved
38.0
Reserved
39.0
Reserved
40.0
Reserved
