Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
333
3.6.9
Motor Parameter object
Selected device parameters of the SIMOCODE pro V EtherNet/IP device can be read or
written via the Motor Parameter object. This allows the device parameters to be adjusted via
the controller or a connected control system.
● Class code: 0x0099
● Class attributes: 0
● Number of instances: 1
● Object length: 116 bytes
Table 3- 99
General services for the Motor Parameter object
Service code
Available service
Service designation
Description
Class
Instance
0x0E
No
Yes
Get_Attribute_Single
Supplies contents of one attribute
0x10
No
Yes
Set_Attribute_Single
Changes an attribute value
Table 3- 100
Attributes of instance 1 for the Motor Parameter object
Attribute ID
Access
Designation
Data
type
Range of values
Unit
1
Get/ Set
Motor protection - set current Is1
LINT
1)
10 mA
2
Get/ Set
Motor protection - set current Is2
LINT
1)
10 mA
3 Get/ Set Motor protection - class SINT 5, 7, 10, 15, 20, 25,
30, 35, 40
4
Get
Reserved
SINT
5
Get
Reserved
INT
6
Get/ Set
Trip level I>
INT
0 .. 255
4% / I_s
7
Get/ Set
Warning level I>
INT
0 .. 255
4% / I_s
8
Get/ Set
Trip level I<
INT
0 .. 255
4% / I_s
9
Get/ Set
Warning level I<
INT
0 .. 255
4% / I_s
10
Get/ Set
Stalled rotor level
INT
0 .. 255
4% / I_s
11
Get/ Set
Trip level U<
INT
0 .. 255
8 V
12
Get/ Set
Warning level U<
INT
0 .. 255
8 V
13
Get/ Set
Trip level cos phi<
SINT
0 .. 100
1 %
14
Get/ Set
Warning level cos phi<
SINT
0 .. 100
1 %
15
Get/ Set
Trip level P>
DINT
0..0xFFFFFFFF
1 W
16
Get/ Set
Warning level P>
DINT
0..0xFFFFFFFF
1 W
17
Get/ Set
Trip level P<
DINT
0..0xFFFFFFFF
1 W
18
Get/ Set
Warning level P<
DINT
0..0xFFFFFFFF
1 W
19
Get/ Set
EM+ - trip level
DINT
30 .. 40000
1 mA
20 Get/ Set EM+ - warning level DINT 30 .. 40000 1 mA
21
Get/ Set
TM1 - trip level T>
DINT
0 .. 65535
1 K
