Siemens SIMOCODE pro Function Manual

Tables, data records
3.4 Tables, PROFINET data records
SIMOCODE pro - Communication
226 Function Manual, 11/2018, A5E40508495002A/RS-AC/003
3.4.2.2
Data record 63 - Analog value recording
You can read out the data of the "Analog value recording" function stored in the device.
Table 3- 53 Data record 63 - Analog value recording
Byte.Bit
Designation
Type
Range
Information
0.0
StartPos
Word
0
2.0
Channel No.
Byte
1
3.0
Analog value record currently running
Bit
0, 1
3.1 Trigger event occurred Bit 0, 1
3.2
Reserved
Bit[6]
0
4.0
Measured value (0)
Word
0 - 65535
6.0
Measured value (1)
Word
0 - 65535
...
122.0
Measured value (59)
Word
0 - 65535
124.0
Reserved
Byte[76]
0
The unit of the measured value is dependent on the assigned analog value. You will find all
available analog values with their units in Chapter Socket assignment table - analog
(Page 219).
3.4.2.3
Data record 67 - Process image output
Table 3- 54 Data record 67 - Process image output
Byte.Bit
Designation
Default (also see parameters)
Type
Information
0.0
Cyclic receive - Bit 0.0
Control station - PLC/PCS [PN] ON<
Bit
0.1
Cyclic receive - Bit 0.1
Control station - PLC/PCS [PN] OFF
Bit
0.2
Cyclic receive - Bit 0.2
Control station - PLC/PCS [PN] ON>
Bit
0.3
Cyclic receive - Bit 0.3
Test 1
Bit
0.4
Cyclic receive - Bit 0.4
Motor protection - Emergency start
Bit
0.5
Cyclic receive - Bit 0.5
Mode selector S1
Bit
0.6
Cyclic receive - Bit 0.6
Reset 1
Bit
0.7
Cyclic receive - Bit 0.7
Not assigned
Bit
1.0
Cyclic receive - Bit 1.0
Not assigned
Bit
1.1
Cyclic receive - Bit 1.1
Not assigned
Bit
1.2 Cyclic receive - Bit 1.2 Not assigned Bit
1.3
Cyclic receive - Bit 1.3
Not assigned
Bit
1.4
Cyclic receive - Bit 1.4
Not assigned
Bit
1.5
Cyclic receive - Bit 1.5
Not assigned
Bit
1.6
Cyclic receive - Bit 1.6
Not assigned
Bit
1.7
Cyclic receive - Bit 1.7
Not assigned
Bit
2.0
Cyclic receive - analog value 1
Not assigned
Word
4.0
Cyclic receive - analog value 2
Not assigned
Word
6.0
Reserved
Bytes[4]
