Siemens SIMOCODE pro Function Manual

Tables, data records
3.6 EtherNet/IP data tables
SIMOCODE pro - Communication
Function Manual, 11/2018, A5E40508495002A/RS-AC/003
331
3.6.8
Statistical Data object
The Statistical Data object supplies the statistical data (such as operating hours, number of
overload trips, number of starts, etc.) of the SIMOCODE pro V EtherNet/IP device.
● Class code: 0x0098
● Class attributes: 0
● Number of instances: 1
● Object length: 228 bytes
Table 3- 97
General services for the Statistical Data object
Service code
Available service
Service designation
Description
Class
Instance
0x01
No
Yes
Get_Attributes_All
Supplies contents of all attributes
0x0E
No
Yes
Get_Attribute_Single
Supplies contents of one attribute
Table 3- 98
Attributes of instance 1 for the Statistical Data object
Attribute
ID
Access
Designation
Data
type
Range
Unit
1
Get
Permissible starts - actual value
INT
0 - 255
2
Get
DM-F - Time until test required
INT
0 - 255
1 week
3
Get
Reserved
DINT
4
Get
Number of parameterizations
DINT
0 - 65535
5 Get Number of overload trips DINT 0 - 65535
6
Get
Int. number of overload trips
DINT
0 - 65535
7
Get
Motor stop time
DINT
0 - 65535
1 h
8
Get
Timer 1 actual value
DINT
0 - 65535
100 ms
9
Get
Timer 2 actual value
DINT
0 - 65535
100 ms
10
Get
Timer 3 actual value
DINT
0 - 65535
100 ms
11
Get
Timer 4 actual value
DINT
0 - 65535
100 ms
12
Get
Counter 1 actual value
DINT
0 - 65535
13
Get
Counter 2 actual value
DINT
0 - 65535
14
Get
Counter 3 actual value
DINT
0 - 65535
15
Get
Counter 4 actual value
DINT
0 - 65535
16
Get
Calculation module 1 output
DINT
0 - 65535
17
Get
Calculation module 2 output
DINT
0 - 65535
18..19
Get
Reserved
DINT[2]
20
Get
Motor operating hours
DINT
0..0x7FFFFFFF
1 s
21
Get
Int. Motor operating hours
DINT
0..0x7FFFFFFF
1 s
22
Get
Device operating hours
DINT
0..0x7FFFFFFF
1 s
23
Get
Number of starts
DINT
0..0x7FFFFFFF
